High speed interface cables for machine vision applications
1394.a long cable
This long-distance cable conforms to the IEEE1394 standard (4.5m). It can transmit data over a maximum distance of 20m at 400Mbps, a maximum distance of 30m at 200 Mbps, and a maximum distance of 50m at 100 Mbps.
High sliding 1394.a cable
The 1394.a cable has excellent sliding resistance. Although the maximum cable length is 4.5m, the cable can be combined with a 1394 long cable series, enabling it to be used for the sliding parts of production equipment, etc.
1394.b long cables
These long-distance cables conform to the IEEE1394.b standard (4.5m).They can transmit data over a maximum distance of 10m at 800Mbps. The first long cable in the industry to clear the IEEE1394.b standard and These thin design type cables are suitable for efficient cable installation such as factory automation systems.
High sliding 1394.b cable
This 1394.b cable has excellent sliding resistance. It can transmit high-speed images at a maximum speed of 800 Mbps, and is optimum for industrial applications such as various kinds of inspection equipment.
Camera link cable (UL20276)
This cable is intended for use with a camera link, which is an interface used with a high-speed, high-sensitivity video camera, or the like.
High sliding camera link cable
This camera link cable has excellent sliding performance. It supports high-speed image transmission, and is optimum for industrial applications such as various kinds of inspection equipment.
Highly flexible Cat.5e LAN cables
These are highly flexible shielded cables which uses a special polymer and a special shield resulting in unprecedentedly high bending and sliding resistance and also increased twisting resistance. They support Gigabit Ethernet and are ideal for high-speed transmission of images using industrial Ethernet, industrial machine vision, and so on.
High sliding, composite LVDS cable
Because of its sliding performance and flexibility, this high sliding, composite LVDS cable is optimum for sliding parts and moving parts of industrial equipment, the handset operation section of various kinds of equipment, etc.
Metal-braid armored cable
This type of cable consists of various kinds of high-speed transmission cables fitted with special metal-braid armor. It is used for various industrial applications and also in shipping.
- *1 : The above cables are sold as wire harnesses.
